Used for the transportation of high-speed rail track slab casting-curing; supports the transportation of material racks with and without support legs, without limitations on product types or industries. The AGV can stealthily enter the bottom of the material rack and lift it for transportation; the dimensions of the material rack match the dimensions of the AGV. It features a dual-drive structure, with hydraulic cylinder lifting.
Feel free to Get in touch
product details:
High cost performance
In the field of heavy-duty AGVs, Lonyu has always been in a leading position in technology. In terms of total weight, we were the first to realize a product with a total weight of 240 tons, then 360 tons, and are currently deploying a 600- ton AGV. Our technical reserves have achieved solution implementation capabilities from 1 to 1,000 tons, allowing us to meet the needs of different customers . As a Chinese enterprise, we maintain reasonable prices while maintaining technological leadership, good quality and stable performance. Our advantage lies in our strong supply chain and excellent project management, which perform well in terms of delivery speed, quality and price. LONYU’s concept is Moving the world ! We hope that smart AGVs can enter more companies and bring comprehensive improvements in safety, efficiency, and intelligence to factories. Lonyu AGV, the product is part of the solution, and also provides Lonyu technical support and quality assurance. No matter where your factory is, we insist on sending engineers to the site to complete our solution to ensure the perfect deployment of Lonyu heavy-duty AGV .
Product Name | Backpack heavy-load AGV |
Model Number | LY-AU-30T-40B |
Product Weight | 5T |
Load Weight | 30T |
Product Size | L5230*W1800*550mm |
Drive Unit Type | Superdrive |
Drive Unit Number | 4-Drive |
Drive Unit Load Weight | 10 |
Remote Control | Manual Remote + Automatic Operation |
Navigation Type | Magnetic Stripe |
Lift Ability | Yes |
Castor | 0 |
Linkage Mode | Single AGV |
Frame Structure | Tubesheet |
Suspension Type | Hydraulic |
Turning Radius | 1530mm |
Voltage | 48V |
Range/Battery | 200AH |
Fixture/Tooling | / |
Explosion-proof level | – |
Explosion-proof or not | No |
